S05HS15-1WH2 Isolated DC-DC Converter – 15 V, 1 W, SIP Module

Original price was: ₹130.00.Current price is: ₹125.00.

SKU: 5057 Category: Tags: , , , , , ,
Brand:HenLV

Description

S05HS15-1WH2 Isolated DC-DC Converter by HenLv Power is a compact power module that delivers 15 V output at 1 W from a 4.75–5.25 V input. Its reinforced isolation capability (up to 3000 V) makes it suitable for industrial control, communication, and embedded applications.

Specification Details
Input Voltage 4.75 V – 5.25 V
Output Voltage 15 V
Output Power 1 W (67 mA)
Isolation Voltage 3000 V (reinf.)
Efficiency Up to 86%
Operating Temp. -40 °C to +85 °C (with derating)
Configuration Single Output, SIP Through-Hole

Applications

  • Industrial control circuits
  • Communication systems
  • Embedded and isolated power needs
  • Instrumentation in harsh environments

How to Use

  1. Mount the SIP module securely on your PCB power section.
  2. Ensure input supply is within 4.75–5.25 V, with decoupling caps nearby.
  3. Connect the 15 V output to your load; observe current limit of 67 mA.
  4. Maintain breathability and thermal management in derating environments.

Why Choose S05HS15-1WH2?

This module provides compact, reliable isolated power in a SIP package with excellent efficiency (~86%) and high isolation (3000 V), ideal for safely powering sensitive industrial systems.
