Description
The 1SS353TFTE-17 Switching Diode is a high-performance, fast switching diode that offers low forward voltage and low capacitance, making it ideal for high-frequency and signal switching applications. Its compact SMD package ensures easy integration into modern electronic devices where space-saving and efficiency are crucial.
Technical Specifications
| Parameter | Details |
|---|---|
| Part Number | 1SS353TFTE-17 |
| Type | High-Speed Switching Diode |
| Package | SMD |
| Forward Voltage (Vf) | 0.72V (typical) |
| Reverse Current (Ir) | 100nA (typical) |
| Junction Capacitance | 1.5pF |
| Max Reverse Voltage | 80V |
| Max Forward Current | 100mA |
| Operating Temperature | -55°C to +150°C |
Applications
- High-speed signal switching
- Communication equipment
- Consumer electronics
- Test and measurement devices
- Power supply switching
How to Use
- Mount the diode in the correct polarity as per circuit design.
- Ensure the voltage and current ratings do not exceed specified limits.
- Integrate into high-frequency circuits where fast response is required.
