Description
LED 3mm 3-Pin Common Anode Red & Yellowish-Green Dual LED
The LED 3mm 3-Pin Common Anode Red & Yellowish-Green Dual LED is a compact dual-color indicator LED designed for multi-state signaling. With a common anode configuration, this LED combines bright red and yellowish-green emitters in a single 3mm lens, making it ideal for status indication, embedded systems, and control panels. Its low power consumption and clear illumination make it reliable for professional and hobby electronics projects.
| Specification | Details |
|---|---|
| LED Type | 3mm Dual-Color LED |
| Colors | Red & Yellowish-Green |
| Pin Configuration | 3-Pin, Common Anode |
| Forward Voltage (Red) | 1.8V – 2.2V |
| Forward Voltage (Yellowish-Green) | 2.0V – 3.0V |
| Forward Current | 20mA per LED |
| Lens Type | 3mm Round Lens |
| Applications | Status indication, dual-color signaling, logic monitoring, embedded projects |
Applications
- Dual-color indicator circuits
- Arduino, ESP32, Raspberry Pi projects
- Control panels and dashboards
- Multi-state signal indicators
- Consumer electronics
- Debugging and fault detection systems
How to Use
- Identify the common anode pin (usually the longest pin).
- Connect the anode to the positive supply (VCC).
- Connect a current-limiting resistor (330E–1K) to each cathode pin.
- Ground the red cathode to illuminate red.
- Ground the yellowish-green cathode to illuminate green.
- Pulse both pins to create mixed or blended color effects.
