S2M SMB – 2A 1000V Surface Mount Rectifier Diode
The S2M SMB is a high-efficiency surface-mount rectifier diode designed for general-purpose rectification in power supplies, converters, and electronic circuits. With a peak reverse voltage of 1000V and a forward current capacity of 2A, this diode ensures stable and efficient power conversion.
Encased in an SMB (DO-214AA) package, the S2M diode provides excellent thermal performance and surge capability. Its compact size and low forward voltage drop make it ideal for applications where space-saving and power efficiency are crucial.
Commonly used in AC to DC converters, LED drivers, and power adapters, the S2M SMB rectifier diode offers fast switching speed and reliable operation. Its ability to handle high surge currents makes it suitable for protecting circuits against voltage spikes.
S2M SMB Rectifier Diode – Technical Specifications
| Parameter | Specification |
|---|---|
| Model | S2M SMB |
| Package | SMB (DO-214AA) |
| Peak Reverse Voltage (VRRM) | 1000V |
| Average Forward Current (IF(AV)) | 2A |
| Surge Current (IFSM) | 50A |
| Forward Voltage Drop (VF) | 1.15V at 2A |
| Reverse Recovery Time (trr) | 2.5µs |
| Operating Temperature Range | -65°C to 150°C |
| Applications | Power rectification, AC to DC conversion, LED drivers, adapters |
Purchase the S2M SMB rectifier diode now from GSSuperstore.in for reliable and efficient power rectification solutions.
