STQ1NK60ZR-AP – N-Channel Power MOSFET 600V 1A TO-92 Package

The STQ1NK60ZR-AP is a high-voltage, low-current N-channel MOSFET designed by STMicroelectronics. It features a 600V maximum drain-source voltage and a 1A continuous drain current, making it an excellent choice for low-power switching, energy-efficient circuits, and compact power supply designs. Its small TO-92 package allows easy integration into space-constrained designs.

Technical Specifications

Applications

• Low-power AC-DC converters
• Switching regulators
• LED drivers
• Battery-operated circuits
• General-purpose low-power switching

How to Use

1. Connect the drain to the load and the source to ground or negative terminal.
2. Drive the gate with a suitable logic-level voltage for switching control.
3. Use a gate resistor if required to control switching speed and reduce oscillations.
4. Ensure heat dissipation if operating close to the maximum current rating.

The STQ1NK60ZR-AP N-channel MOSFET is an efficient, compact, and reliable solution for low-power switching applications. With its robust design and 600V rating, it is a preferred choice in power supply and general-purpose electronics.
