URD12S05-50W DC‑DC Converter – 12–36 V to 5 V@10 A | 50 W Metal Enclosed Module
URD12S05-50W from HenLv Power is a high-efficiency, board-mount isolated DC‑DC converter that delivers 5 V at 10 A (50 W) from a wide input range of 9–36 V DC. Its shielded metal case ensures EMI protection, thermal stability, and reliability in industrial, telecom, and embedded applications.
Technical Specifications:
| Specification | Details |
|---|---|
| Part Number | URD12S05-50W |
| Input Voltage | 9–36 V DC |
| Output Voltage / Current | 5 V DC @ 10 A (50 W) |
| Efficiency | ≈80–88% typical |
| Isolation | Full galvanic isolation (class 1500 VDC rating) |
| Case | Metal shielded through-hole module |
| Dimensions | 50.8 × 25.4 × 12.5 mm (2.00″ × 1.00″ × 0.49″) |
| Operating Temp. | –40 °C to +85 °C |
| Protections | Over-current, short-circuit, thermal shutdown |
Compliance & Safety:
- CE certified, meets EN 55032 EMI standards
- Rugged metal housing enhances thermal and EMI resilience
Applications:
- Industrial control systems
- Telecom & networking power supplies
- Embedded instrumentation
- Robotics and automation platforms
- Any application requiring isolated 5 V/10 A output
Order the URD12S05-50W DC‑DC Converter at GSSuperstore.in—trusted for high‑power, reliable isolated power solutions.
