Description
LED 10mm Diffused Red – High Brightness Through-Hole Indicator LED
| Specification | Details |
|---|---|
| LED Diameter | 10mm |
| Lens Type | Diffused Red Lens |
| Color Output | Red |
| Forward Voltage (VF) | 1.8V – 2.2V |
| Forward Current | 20mA (typical) |
| Viewing Angle | 40° – 60° (Wide beam) |
| Mounting Type | Through-Hole (DIP) |
The LED 10mm Diffused Red is a widely used indicator LED designed with a soft, evenly distributed light output thanks to its diffused lens. The 10mm large-size body provides excellent brightness visibility even in indoor lighted conditions. Ideal for display panels, indicators, DIY projects, and educational electronics, this LED delivers stable, long-lasting red illumination.
Applications
- Signal indicators and status lights
- Control panels and instrument indicators
- DIY hobby electronics
- Model lighting and decorative electronics
- Learning kits and student projects
How to Use
- Identify the long leg (anode) and short leg (cathode).
- Connect the anode to +V and the cathode to ground.
- Use a current-limiting resistor (220E to 470E for 5V circuits).
- Insert the LED into breadboards or PCBs using its DIP pins.
- Operate within its recommended current for long lifespan.
Why Choose LED 10mm Diffused Red?
This LED provides a wide-angle light output, making it ideal for soft glow indicators and visual notifications. Its diffused lens reduces hotspots, ensuring smooth light distribution, perfect for both professional and DIY projects.
